(1998) 14" Philips 14PV172/13

(1998) 14" Philips 14PV172/13

Screen diameter: 14" / 37cm
Visible Screensize: 34cm
CONNECTIONS
Front: headphones (3.5 mm jack)
Rear: Scart
Antenna connector

Mains: AC 220-240 V +/- 10%
50 Hz
Music output: 4 W
Loudspeaker: Full-range 4"
Remote Control: RT 770
Local keyboard: -
Timer: 24 hour "wake up" / 3 hour sleep
Tuning system: PLL (one tuner)
Transmission systems (/01, /08, /13): PAL BG
Number of presets: 69
Backup of presets: 1 year
Hyperband
Cable tuner incl. incl. S-channels
ShowView/ VideoPLUS
Number of events: 6
Cursor controlled parallel programming
PDC/ VPS (/01, /39)
Backup of clock: 7 hours
Full cursor controlled menu system
Sender identification (PDC/VPS /01, /39)
Languages: GB, DK, FI, NO, SW

VCR FUNCTIONS
Lasered Video heads: 2
Winding time E180 (sec): 170
Eject to play (sec): 4.5
Stop to play (sec): 0.4
Full loaded wind
Automatic head cleaner
Cleaning mode
Tape counter: elapsed time
VISS next/ previous index search
Still
Play: + 1
Reverse play: - 1
Fast: +3 / -3
Scan: +9/ -9
NTSC playback
LP for UK only
Edge noise canceller
HQ +: >240 lines
Studio tracking
Assemble
Auto play
Auto rewind: after play
Auto eject: after record

Power consumption: <50 W
Standby power: <10W
Weight (approx.): 13 kg
Dimensions (w x h x d): 375 x 392 x 374 mm
Childlock
Hotelmode
Chassis: Vienna Combi 97
