(early 1970s) 17.3" SABA Schauinsland P 171 elektronic K

(early 1970s) 17.3" SABA Schauinsland P 171 elektronic K

Screen Size: Approximately 44 cm (17.3 inches) diagonal
Dimensions: Approximately 525 mm (W) x 365 mm (H) x 315 mm (D) [20.7 x 14.4 x 12.4 inches].

Type: Black-and-white CRT (Cathode Ray Tube).
Design:
Cabinet Finish: Available in walnut, light natural, or matte white finishes.
Weight: Approximately 14 kg (30.8 lbs).
Tuning:
Channel Coverage:
VHF: Channels 2 to 12.
UHF: Channels 21 to 60.
Antenna Input: 240 Ohm symmetrical.
Channel Selection: 6 preset channel buttons.
Audio:
Speaker: Built-in speaker measuring 8 x 12 cm.
Electronics:
Tubes: Utilizes 5 tubes, including the PCL805.
Semiconductors: Incorporates 17 transistors and 35 diodes.
Power:
Supply: Operates on standard AC mains voltage.
